ENGENIUS EPA5060XBT 60W 10GB SINGLE-PORT POWER-OVER-ETHERNET (POE++) ADAPTER
$47.99
In stock
SKU
TWS-ENG-EPA5060XBT
Warranty
One year warranty and hassle free returns
Estimated Delivery
5-7 business days
We Accept Visa, Mastercard, American Express, and Discover
POE12-30W 2.5G POE+ 30 WATT INJECTOR (POE12HP REPLACEMENT) Previous
Overview
The ENGENIUS EPA5060XBT 60W 10GB SINGLE-PORT POWER-OVER-ETHERNET (POE++) ADAPTER delivers 60W capacity. Manufactured to meet industry standards for reliable connectivity in structured cabling and network infrastructure deployments.
Key Specifications
Capacity
60W
PoE
Power over Ethernet
Warranty
Manufacturer Warranty Included
Condition
New — Factory Sealed
Ideal For
Network Infrastructure
Reliable connectivity for wired environments
Data Center Cabling
High-performance cables for rack deployments
Desktop Connectivity
Connect displays, docks, and peripherals
Full Technical Specifications
31 specs · 5 categories
| Ethernet LAN data rates | 10,100,1000,2500,10000 Mbit/s |
| Ethernet interface type | 2.5 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
Physical
| Width | 3.94" (100 mm) |
| Height | 1.31" (33.4 mm) |
| Depth | 2.3" (58.4 mm) |
| Weight | 6.98 oz (198 g) |
| Product color | Black |
Environment
| Operating temperature (T-T) | 0 - 40 °C |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), UL |
Packaging
| Package width | 4.84" (123 mm) |
| Package depth | 2.05" (52 mm) |
| Package height | 5.98" (152 mm) |
| Package weight | 11.1 oz (315 g) |
Other Specifications
| Wall mountable | Yes |
| LED indicators | Power |
| Output power | 60 W |
| Power protection features | Over current, Over voltage, Short circuit |
| Pin assignment & polarity | Pin4(Vdc+)&Pin5(Vdc+); Pin7(Vdc-)&Pin8(Vdc-); Pin1(Rx+)&Pin2(Rx-); Pin3(Tx+)&Pin6(Tx-) |
| Quantity per master (outer) case | 40 pc(s) |
| Master (outer) case width | 10.6" (270 mm) |
| Master (outer) case length | 20.5" (520 mm) |
| Master (outer) case height | 13.8" (350 mm) |
| Master (outer) case weight | 29.8 lbs (13.5 kg) |
| Storage temperature (T-T) | -20 - 70 °C |
| Input voltage | 100 - 240 V |
| Input current | 1.12A @ 120V AC, 0.75A @ 240V AC |
| Input frequency | 50 - 60 Hz |
| Surge protection voltage | 4 kV |
| Power over Ethernet (PoE) voltage | 54 V |
| Warranty period | 1 year(s) |
Specifications sourced from ICEcat and manufacturer datasheets. Confirm critical specs with the manufacturer before purchase.
What's in the Box
Cable/Adapter
