5-PORT POE++ SWITCH WITH 4 GIGABIT ETHERNET PORTS AND 1 RJ45 GIGABIT UPLINK PORT
$225.99
In stock
SKU
TWS-ICI-562010
Icecat · 5-port · RJ45
See all Specs
Warranty
One year warranty and hassle free returns
Estimated Delivery
5-7 business days
We Accept Visa, Mastercard, American Express, and Discover
2 PORT USB HDMI KVM SWITCH W/ AUDIO Previous
Overview
The 5-PORT POE++ SWITCH WITH 4 GIGABIT ETHERNET PORTS AND 1 RJ45 GIGABIT UPLINK PORT from Icecat with 5-port configuration. Engineered for enterprise network deployments, this solution delivers the reliability and performance that IT teams depend on.
Key Specifications
Ports
5-port
PoE
Power over Ethernet
Connector
RJ45
Ideal For
Enterprise Networks
Scalable switching for growing organizations
Data Centers
High-density port configurations for rack deployments
Managed Infrastructure
VLAN, QoS, and access control capabilities
Full Technical Specifications
41 specs · 6 categories
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
| Jumbo frames support | Yes |
| Rack mounting | No |
Power
| Power consumption (max) | 150 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Physical
| Width | 6.61" (168 mm) |
| Height | 1.26" (32 mm) |
| Depth | 3.7" (94 mm) |
| Weight | 13.9 oz (395 g) |
| Product color | Black |
| Rack mounting | No |
Environment
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Certification | FCC, CE, RoHS, UKCA, NDAA |
Packaging
| Cables included | AC |
| Package width | 8.9" (226 mm) |
| Package depth | 9.45" (240 mm) |
| Package height | 3.31" (84 mm) |
| Package weight | 3.2 lbs (1.45 kg) |
Other Specifications
| MAC address table | 2000 entries |
| Switching capacity | 10 Gbit/s |
| Forwarding rate | 7.44 Mpps |
| Store-and-forward | Yes |
| Jumbo frames | 9216 |
| Packet buffer memory | 1 MB |
| Wall mountable | Yes |
| LED indicators | Activity, Link, PoE, Power |
| Power protection features | Over voltage, Overload, Short circuit, Surge protection |
| Quantity per master (outer) case | 10 pc(s) |
| Master (outer) case width | 10" (254 mm) |
| Master (outer) case length | 17.6" (446 mm) |
| Master (outer) case height | 19.1" (486 mm) |
| Master (outer) case weight | 33.5 lbs (15.2 kg) |
| Switch type | Unmanaged |
| Cable types supported | Cat5e |
| Auto MDI/MDI-X | Yes |
| Full duplex | Yes |
| Flow control support | Yes |
| 10G support | No |
Specifications sourced from ICEcat and manufacturer datasheets. Confirm critical specs with the manufacturer before purchase.
What's in the Box
Switch
Power Cord
Rack Mount Brackets
Console Cable
Quick Start Guide
